MECHANICAL PARAMETERS
|
Main Material |
Q235B / Q355B / ZAM(S440/S550） |
|
Fastener Material |
304 stainless steel |
|
Warranty |
Whole machine 5 years (Except for man-made damage and force majeure) |
|
Protection Wind Speed |
20 m/s |
|
Survival Wind Speed |
37～50m/s (ASCE7-10, other wind speeds can be |
|
Snow Load |
0.8～1.1KN/㎡ |
|
Drive Device |
Linear drive |
|
Drive Type |
Multi-point drive |
|
Azimuth Tracking Range (°) |
-50°～+50° (Customizable) |
CONTROLLER PARAMETERS
|
Control Algorithm |
Astronomical Algorithm + Intelligent Tracking Technology+ Synchronous drive of multiple drives |
|
|
Communication Protocol |
RS485 |
|
|
Communication Type |
Wired / Wireless |
|
|
Protection Level |
IP65 |
|
|
Wind Protection |
Have |
|
|
Night Return Mode |
Have |
|
|
Backtracking Algorithm |
Have |
|
|
Rotation Position Protection Mode |
Sensor protection + Software protection |
|
|
Tracking Range (°) |
≤1° |
|
|
Working Temperature (℃) |
Default Configuration -30℃～+70℃ (Customizable) |
|
|
Flat at Night |
Have |
|
|
Heavy Rain Cleaning Mode |
Optional |
|
|
Automatic Snow Removal |
Optional |
|
APPLICABLE TERRAIN
According to the longitude, latitude, altitude and time of the project site, the program automatically calculates the sun's running track at any time and the azimuth and altitude angle of the location, and adjusts the tracking angle once every other period of time, so that the PV module is always aligned with the current sun's position, while the tracking system is fixed for the rest of the time.
SCADA
Tracker Monitoring & Alarm + System Diagnosis + Intelligent Control
AI intelligent control system, asymmetrical backtracking algorithm and diffuse reflection tracking algorithm and smarter gale protection algorithm can be adopted according to real-time weather and site conditions.
- Remote data management
- Data analysis
- Remote data monitoring
SYSTEM MODE
Lower Torsional Fluttering
- Higher Critical Wind Speed
- Higher Power Density
- Lower Failure Rate
Maximum Wind Resistance Stability
Multi-drive structure can shorten the distance of torque transmission, effectively improve the transmission efficiency of force, adapt to various strong wind conditions to ensure a safer structure and a more reliable wind speed resistance performance and higher tracking accuracy.
Automatic Rain and Snow Cleaning Mode
Incorporate smart cleaning algorithm to run optimal solar module cleaning solutions in multiple weather patterns.
LONG WARRANTY PERIOD
The whole machine for 5 years,steel structure for 10 years. (Except for man-made damage and force majeure)
