Description
Description



   MECHANICAL PARAMETERS

   Design Specification    ASCE7 EN1991 AS1170 GB50009-2012
   Warranty    Whole machine 5 years (except for man-made damage and force majeure)
   Main Material    Q235B/Q355B/ZAM
   Galvanizing Thickness    >85um
   Fastener Material    304 stainless steel
   Mechanical Design Life (Y)    >25
   Protection Wind Speed    17 m/s
   Survival Wind Speed    37m/s(Wind Speed Can Be Customized,<46m/s)
   Snow Load    0.2~0.8KN/㎡
   Basic Form    Concrete Foundation (Ground Screw/ Static Pile)
   Drive Device    Single Drive / Dual drive



   CONTROLLER PARAMETERS

   Controller Type    MCU
   Control Algorithm    Astronomical algorithm + Position sensor closed loop control
   Communication Protocol    RS485
   Communication Type    Local Network: LoRa(Group Control)     Remote Network: Wired Communication / Wireless Communication / WIFI or 4G(Optional)
   Protection Level    IP65
   Gale Protection    Have
   Night Return Mode    Have
   Backtracking Algorithm    Have
   Rotation Position Protection Mode    Sensor protection + Software protection
   Tracking Range (°)    -60°~+60°
   Tracking Accuracy (°)    ≤1°
   Automatic Snow Removal    Optional


   APPLICABLE TERRAIN


   SCADA

Tracker Monitoring & Alarm + System Diagnosis + Intelligent Control
AI intelligent control system, asymmetrical backtracking algorithm and diffuse reflection tracking algorithm and smarter gale protection algorithm can be adopted according to real-time weather and site conditions.
- Remote data management

- Data analysis
- Remote data monitoring




   OPERATION MODE
According to the project of longitude, latitude, elevation, time, the program automatically calculates any time the sun's orbit and location of the azimuth and altitude Angle. The system automatically gives instructions according to the tracking range to control the operation of the electric actuator, and adjusts the tracking Angle every once in a while, so that the photovoltaic module is always aligned with the current position of the sun, the panel is aligned with the sun, and the tracking system is fixed the rest of the time.
